AC Rotating Exciter 500kw Jichai Diesel Generator for Ordinary Landuse Power Generation

Large Image : AC Rotating Exciter 500kw Jichai Diesel Generator for Ordinary Landuse Power Generation

Product Details:

Place of Origin:	china
Certification:	ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	10-1000
Packaging Details:	Wooden box and carton packaging
Delivery Time:	15 days
Payment Terms:	TT,western

Contact Now

AC Rotating Exciter 500kw Jichai Diesel Generator for Ordinary Landuse Power Generation

Description

Model NO.:	12V190	Conditions Of Use:	Land Use
Usage:	Common Units	Landuse Type Of Unit:	Ordinary
Excitation Mode:	AC Rotating Exciter	Transport Package:	Wooden Cases
Specification:	11	Trademark:	JICHAI
Origin:	China	HS Code:	8409999000
Supply Ability:	50000pecises/Year	Type:	Basic Diesel Generator
Installation Method:	Fixed	Stroke:	Four Stroke
Cooling Method:	Water Cooling	Output Type:	DC
Speed:	HSS	Customization:	Available \| Customized Request

Main specification for gas gesets
Model of genset	Model of engine	Rated Power(KW/KVA)	Rated Voltage(V)	Rated Frequency(HZ)	Overall Dimension LBH(mm)	Net weigh(KG)	Fuel
400GF-MK1	12V190ZLM-2	400/500	400/230	50	512020402678	12000	coal gas
500GF-TK	G12V190ZLT-2	500/625	400/230	50	512020402678	12000	natural gas
500GF-MK1	12V190ZLM	500/625	400/230	50	512020402678	12000	coal gas
500GF-MK2	12V190ZLM-2	500/625	400/230	50	512020402678	12000	coal gas
500GF-LK	G12V190ZL-2	500/625	400/230	50	512020402678	12000	refinery gas
700GF-TK	G12V190ZLT	700/875	400/230	50	512020402678	12000	natural gas
Main specification for gas engines
Model	Rated Power(KW)	Rated Speed(r/min)	Compression ratio	No.and layout of cylinders	Overall Dimension LBH(mm)	Net weigh(KG)	Fuel
12V190ZLM-2	450	1000	10:01	12,60.Vee	278516282437	5300	coal gas
G12V190ZLL-2	550	1000	10:01	12,60.Vee	278516282437	5300	refinery gas
12V190ZLM	550	1500	10:01	12,60.Vee	278516282437	5300	coal gas
G12V190ZLT-2	600	1000	10:01	12,60.Vee	278516282437	5300	natural gas
12V190ZLZ	700	1500	10:01	12,60.Vee	278516282437	5300	biogas
G12V190ZLT	800	1500	10:01	12,60.Vee	278516282437	5300	natural gas
12V190ZLT	800	1500	10:01	12,60.Vee	267015882538	5300	natural gas
Main technical data
Type:Four stroke,water cooled,turbocharged and aftercooled,spark plug ignition,outer mixing
Bore:190mm
Stroke:210mm
Direction of rotation:Counter-clockwise(facing to flywheel)
Starting method: electric motor
Lubricating method:Pressure and splash lubrication
Specific heat consumption:≤9800KJ/KW·h
Specific oil consumption:≤1.6g/KW·h
Stable speed regulating rate:0-5%adjustable

Jinan Guohua Green Power Equipment Co.,Ltd(JNGH),is a high-tech sales &service company of Jinan Diesel Engine Co., Ltd. Established in 2010,JNGH has formed a complete system in sales and after-sales of 190 series engine(jichai brand:6L190,8V190,12V190.16V190)
Main business scope:
Early stage:Consultation,designation, supply and erection of engine-based power plants,including diesel generator,natural gas generator,coal gas generator and biogas generator.
Mid stage:Parts supply of jinan diesel engine(jichai/chidong brand).JNGH has two warehouses.One located in Jinan which supply the domestic north and south market.One located in Xinjiang province which supply the west market.Thus could delivery parts fast and guarantee the quality.
Later stage:JNGH also offer engine overhaul and maintenance service.With experienced engineer and professional skills,the problems could be easy solved.Not only the domestic China,Ghana,Kazakhstan,Vietnam and Myanmar also could see the trace of JNGH.
Later stage:Overhaul and maintenance service offered.
Power project consultation and design, integrated OEM, and spare parts supply are offered by JNGH.As well as this, JNGH provides engine overhaul and maintenance services, and power plant investment. JCHN is also capable of providing EPC integrated solutions and turn-key projects of fuel gas comprehensive utilization system, combined heat utilization system (CHP or CCHP), water treatment system, etc.established in 2010,is a high-tech enterprise specialized in 190 series engine.(6L190,8V190,12V190,16V190).
