Cylinder Arrangement Form V 12V190 Series Marine Engine for Jichai Chidong in Jinan

Large Image : Cylinder Arrangement Form V 12V190 Series Marine Engine for Jichai Chidong in Jinan

Product Details:

Place of Origin:	china
Certification:	ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	10-1000
Packaging Details:	Wooden box and carton packaging
Delivery Time:	15 days
Payment Terms:	TT,western

Contact Now

Cylinder Arrangement Form V 12V190 Series Marine Engine for Jichai Chidong in Jinan

Description

Model NO.:	12V190	Cylinder Arrangement Form:	V
Number Of Cylinders:	12-Cylinder	Transport Package:	Wooden Cases
Trademark:	Jichai	Origin:	China
HS Code:	8409999000	Supply Ability:	50000pieces/Year
Ignition Mode:	Ignition	Speed:	Speed
Cooling Cylinder:	Water-Cooled	Intake Pressure Impulse:	Supercharged
Fuel:	Diesel	Number Of Strokes:	Four-Stroke
Customization:	Available \| Customized Request

8190 Marine Engine Main Technical Data
MODEL	RATED POWER(KW/HP)	RATED SPEED(R/MIN)	SPECIFIC FUEL CONSUMPTION(G/KW'H)	SPECIFIC OIL CONSUPTION(G/KW'H)	OVERALL DIMENTION(MM)	NET WEIGHT (KG)
Z12V190BC1	800/1080	1500	≤209.4	≤1.6	264215882070	5300
Z12V190BC2	882/1200	1500	≤209.4	≤1.6	264215882070	5300
Z12V190BC8	1000/1360	1500	≤209.4	≤1.6	264215882070	5300
Z12V190BC9	882/1200	1500	≤209.4	≤1.6	264215882070	5300
Z12V190BC10	900/1225	1450	≤209.4	≤1.6	264215882070	5300
Z12V190BC11	882/1200	1500	≤209.4	≤1.6	264215882070	5300
G12V190ZLC1	1000/1360	1450	≤209.4	≤1.6	264215882070	5300
G12V190ZLC2	1000/1360	1450	≤209.4	≤1.6	264215882070	5300

Main technical data:
No. and arrangement of cylinders:12,60.Vee
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:210mm
Total displacement:71.45L
Compression ration:14:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication
COMPANY INTRO:

√Click below to contact me for more details√

Jinan Guohua Lveng Power Equipment Co., Ltd. was established on January 15, 2010.The business scope includes electrical equipment, barrel lubricating oil sales;Technical development, design, sales, leasing, repair, maintenance and technical services of gas engines, combustible gas generator sets, diesel engines and diesel generator sets;Technical development, design and sales of the above machine spare parts and required auxiliary materials, mechanical equipment, instruments and meters, power station equipment, industrial monitoring system equipment;Import and export business.(For projects that must be approved according to law, business activities can only be carried out after being approved by relevant departments.) Jinan Guohua Lveng Power Equipment Co., Ltd. has one branch.

After nearly ten years development, the company has formed a complete ,mature sales and maintenance service system. At present, the company has set up a warehouse in Jinan and XinJiang, covering an area of more than 1,000 square meters, And the company also has 2000 square meters of engine overhaul and stalling workshop in jinan, with assets of 30 million yuan, more than50 employees. At present, the company has obtained SGS general notary certificate, 190 series engine agent certificate.

The company's sales network has been continuously expanded. It has established stable supply and marketing relationships with clients from 32 provinces, municipalities and autonomous regions in China.Also the products are sold overseas and have been sold to 20 countries including Asia, Africa, America, and the Commonwealth of Independent States.
Companies adhere to the "quality first, scientific management, customer first, integrity-based" purposes, which are in accordance with the "integrity, pragmatic, pioneering, innovative" spirit of enterprise, so as to meet the needs of users with first class service.

Warmly welcome friends from all walks of life to review, cooperate and create brilliance

12V190 Series-Z12V190bc8 Jichai Chidong Brand Marine Engine in Jinan
