Powerful 4 Stroke A12V190 Chidong Jinan Jichai Marine Engine with 12 Cylinders

Large Image : Powerful 4 Stroke A12V190 Chidong Jinan Jichai Marine Engine with 12 Cylinders

Product Details:

Place of Origin:	china
Certification:	ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	10-1000
Packaging Details:	Wooden box and carton packaging
Delivery Time:	15 days
Payment Terms:	TT,western

Contact Now

Powerful 4 Stroke A12V190 Chidong Jinan Jichai Marine Engine with 12 Cylinders

Description

Model NO.:	A12V190	Transport Package:	Wooden Cases
Specification:	3000KG	Trademark:	Jichai
Origin:	China	HS Code:	8408100000
Supply Ability:	50000pecises/Year	Cylinders:	12
Fuel Type:	Diesel	Engine Capacity:	4.1-5L
Engine:	4 Stroke	Engine Position:	Inboard
Condition:	New	Customization:	Available \| Customized Request

			Series 3000 marine diesel engines
Model	Rated Power(kw/hp)	Rated speed(r/min)	Specific fuel consumption(g/kw'h)	Specific oil consumption(g/kw'h)	Overall dimension LBH(mm)	Net weight(kg)
A12V190ZLC	1200/1630	1500	≤ 205	≤1.0	296919072206	9300
A12V190ZLC1	1080/1470	1450	≤ 205	≤1.0	296919072206	9300
A12V190ZLC-1	900/1225	1200	≤ 205	≤1.0	296919072206	9300
A12V190ZLC-2	810/1100	1000	≤ 205	≤1.0	296919072206	9300
L12V190ZLC-1	1200/1630	1200	≤ 202	≤1.0	295019802312	9300
L12V190ZLC-2	1000/1360	1000	≤ 202	≤1.0	296919802312	9300
Main technical data No. and arrangement of cylinders:12,60.Vee Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection Bore:190mm Stroke:215/255mm Total displacement:73.15/86.72L Compression ration:14.5:1 Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel) Starting method:Air motor or electric motor Lubricating method:Pressure and splash lubrication









Main specification of diesel gensets
Model of generating set	Model of diesel engines	Model of generator	Rated Power KW	Rated voltage V	Rated frequency HZ	Overall dimension LBH(mm)	Net weight KG
CCFJ1000/1500	A12V190ZLCD	1FC6506-4SAA42	1000/1500	390	50	641022522739	20200

Jinan Guohua Green Power Equipment Co.,Ltd(JNGH),is a high-tech sales &service company of Jinan Diesel Engine Co., Ltd. Established in 2010,JNGH has formed a complete system in sales and after-sales of 190 series engine(jichai brand:6L190,8V190,12V190.16V190) after eight years experience.
Main business scope:
Early stage:Consultation,designation, supply and erection of engine-based power plants,including diesel generator,natural gas generator,coal gas generator and biogas generator.
A12V190 Chidong Jinan Jichai Marine Engine

Mid stage:Parts supply of jinan diesel engine(jichai/chidong brand).JNGH has two warehouses.One located in Jinan which supply the domestic north and south market.One located in Xinjiang province which supply the west market.Thus could delivery parts fast and guarantee the quality.
A12V190 Chidong Jinan Jichai Marine Engine

Later stage:JNGH also offer engine overhaul and maintenance service.With experienced engineer and professional skills,the problems could be easy solved.Not only the domestic China,Ghana,Kazakhstan,Vietnam and Myanmar also could see the trace of JNGH.
A12V190 Chidong Jinan Jichai Marine Engine
