4 Stroke Engine 8190 Chidong Jinan Jichai Diesel Engine for Customer Requirements

Large Image : 4 Stroke Engine 8190 Chidong Jinan Jichai Diesel Engine for Customer Requirements

Product Details:

Place of Origin:	china
Certification:	ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	10-1000
Packaging Details:	Wooden box and carton packaging
Delivery Time:	15 days
Payment Terms:	TT,western

Contact Now

4 Stroke Engine 8190 Chidong Jinan Jichai Diesel Engine for Customer Requirements

Description

Model NO.:	8190	Transport Package:	Wooden Cases
Specification:	3000KG	Trademark:	Jichai
Origin:	China	HS Code:	8408100000
Supply Ability:	50000pecises/Year	Cylinders:	4
Fuel Type:	Diesel	Engine Capacity:	4.1-5L
Engine:	4 Stroke	Engine Position:	Inboard
Condition:	New	Customization:	Available \| Customized Request

			8 in-line marine diesel engines
Model	Rated Power(kw/hp)	Rated speed(r/min)	Specific fuel consumption(g/kw'h)	Specific oil consumption(g/kw'h)	Overall dimension LBH(mm)	Net weight(kg)
8190ZLCZ-R	720/980	1450	≤ 204	≤ 1.2	317512202055	5200
8190ZLC	720/980	1450	≤ 204	≤ 1.2	317512202055	5200
8190ZLCZ-1R	600/820	1200	≤202	≤ 1.2	317512202055	5200
8190ZLCZ1-1R	600/820	1200	≤202	≤ 1.2	317512202055	5200
8190ZLC-1	600/820	1200	≤202	≤ 1.2	317512202055	5200
8190ZLC1-1	600/820	1200	≤202	≤ 1.2	317512202055	5200
8190ZLCZ-2R	500/680	1000	≤202	≤ 1.2	317512202055	5200
8190ZLC-2	500/680	1000	≤202	≤ 1.2	317512202055	5200
8190ZLCZ-3R	650/880	1300	≤202	≤ 1.2	317512202055	5200
8190ZLC-3	650/880	1300	≤202	≤ 1.2	317512202055	5200
Main technical data No. and arrangement of cylinders:8-cylinder,in-line Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection Bore:190mm Stroke:210mm Total displacement:47.6L Compression ration:14.5:1 Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel) Starting method:Air motor or electric motor Lubricating method:Pressure and splash lubrication

Jinan Guohua Green Power Equipment Co.,Ltd(JNGH),is a high-tech sales &service company of Jinan Diesel Engine Co., Ltd. Established in 2010,JNGH has formed a complete system in sales and after-sales of 190 series engine(jichai brand:6L190,8V190,12V190.16V190) after eight years experience.
Main business scope:
Early stage:Consultation,designation, supply and erection of engine-based power plants,including diesel generator,natural gas generator,coal gas generator and biogas generator.
8190 Chidong Jinan Jichai Diesel Engine

Mid stage:Parts supply of jinan diesel engine(jichai/chidong brand).JNGH has two warehouses.One located in Jinan which supply the domestic north and south market.One located in Xinjiang province which supply the west market.Thus could delivery parts fast and guarantee the quality.
8190 Chidong Jinan Jichai Diesel Engine

Later stage:JNGH also offer engine overhaul and maintenance service.With experienced engineer and professional skills,the problems could be easy solved.Not only the domestic China,Ghana,Kazakhstan,Vietnam and Myanmar also could see the trace of JNGH.
8190 Chidong Jinan Jichai Diesel Engine
