Product Description
Technical parameters of generator set:
1. Unit model: 1000GF
2. Rated power: 1000KW
3. The rated power factor: COS Φ = 0.8 (lag)
4. Rated output voltage: 400V/230V
5. Rated current: 1800A
6. Rated frequency: 50Hz
7. Rated speed: 1500rpm
8. Start control mode: electric start
9. Full load fuel consumption: 221g/ kW •h
10. Fuel grade :(standard) 0# light diesel oil (normal temperature)
11. Lubricating oil brand :(standard) SAE15W / 40
12. Overall dimension (mm) : 6000*2000*2778
Steady-state voltage adjustment rate: ≤±0.5%
14. Transient voltage adjustment rate: ≤-10%/+15%
15 voltage volatility (%) : ≤±0.5
16. Voltage stability time: ≤1.5sec
17. Voltage waveform distortion: ≤8%
18. Steady-state frequency adjustment: ≤3%
19. Transient frequency adjustment: ≤±5%
20. Frequency stabilization time: 3sec
21. Steady-state frequency adjustment (%) : ≤±1
22 frequency volatility (%) : ≤±0.5
23. Noise (LP1M) : 98dB (A)
24. Weight: 15000KG
Brand: Jichai lubricating oil capacity: 200L
Type: A12V190ZL Class: four stroke, exhaust turbo charged, direct injection compression ignition
Power rate: 1200KW Cooling method: come with fan water tank forced closed circulating water cooling
Number of cylinders: 12/V type speed regulation mode: electronic speed regulation/mechanical speed regulation
Discharge capacity: 73.45L cylinder diameter * stroke: 190mm*215mm
Start mode: DC24V electric start speed: 1500rpm
Our Advantages
COMPANY INTRO: Jinan Guohua Lveng Power Equipment Co., Ltd. was established on January 15, 2010.The business scope includes electrical equipment, barrel lubricating oil sales;Technical development, design, sales, leasing, repair, maintenance and technical services of gas engines, combustible gas generator sets, diesel engines and diesel generator sets;Technical development, design and sales of the above machine spare parts and required auxiliary materials, mechanical equipment, instruments and meters, power station equipment, industrial monitoring system equipment;Import and export business.(For projects that must be approved according to law, business activities can only be carried out after being approved by relevant departments.) Jinan Guohua Lveng Power Equipment Co., Ltd. has one branch. Official website: jinanguohua.en.made-in-china.com Address: 3-201, Building 4, Area 2, Meili Xinju, Huaiyin District, Jinan, Shandong
