800 Mud Pump Jichai Engine for Oil Field/Coal Mine Drilling Rig Drill Hole Depth 200m

Large Image : 800 Mud Pump Jichai Engine for Oil Field/Coal Mine Drilling Rig Drill Hole Depth 200m

Product Details:

Place of Origin:	china
Certification:	ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	10-1000
Packaging Details:	Wooden box and carton packaging
Delivery Time:	15 days
Payment Terms:	TT,western

Contact Now

800 Mud Pump Jichai Engine for Oil Field/Coal Mine Drilling Rig Drill Hole Depth 200m

Description

Model NO.:	12V190	Trademark:	Jichai
Origin:	China	HS Code:	8409999000
Supply Ability:	50000pieces/Year	Certification:	CE, ISO 9001:2000
Condition:	New	Drill Hole Depth:	>200m
Bit Type:	Diamond Bit	Drilling Way:	Compound
Transport Package:	Wooden Cases	Customization:	Available \| Customized Request

800 Mud Pump Jichai Engine Used in Oil Field/Coal Mine Drilling Rig

Diesel engine parameters:
1. Unit model: 500GF

2. Rated power: 500KW

3. The rated power factor: COS Φ = 0.8 (lag)

4. Rated output voltage: 400V/230V

5. Rated current: 900A

6. Rated frequency: 50Hz

7. Rated speed: 1500rpm

8. Start control mode: electric start

9. Full load fuel consumption: 220g/ kW •h

10. Fuel grade :(standard) 0# light diesel oil (normal temperature)

11. Lubricating oil brand :(standard) SAE15W / 40

12. Overall dimension (mm) : 4500*1800*2400

13. Steady state voltage adjustment rate: ≤±0.5%

14. Transient voltage adjustment rate: ≤-10%/+15%

15 voltage volatility (%) : ≤±0.5

16. Voltage stability time: ≤1.5sec

17. Voltage waveform distortion: ≤8%

18. Steady-state frequency adjustment: ≤3%

19. Transient frequency adjustment: ≤±5%

20. Frequency stabilization time: 3sec

21. Steady state frequency adjustment rate (%) : ≤±1

22. Frequency fluctuation (%) : ≤±0.5

23. Noise (LP1M) : 98dB (A)

24. Weight: 6800KG

Brand: Jichai	Lubricating oil capacity: 150L
Type no. : Z8V190D2	Class A: four stroke, exhaust gas turbocharged, direct injection compression - ignition
Number of cylinders: 6/ inline type	Speed regulation mode: electronic speed regulation/mechanical speed regulation
Discharge capacity: 35.73L	Cylinder diameter * stroke: 190mm*210mm
Cylinder diameter * stroke: 190mm*210mm	Transfer rate: 1500 RPM

COMPANY INTRO:

Jinan Guohua Lveng Power Equipment Co., Ltd. was established on January 15, 2010.The business scope includes electrical equipment, barrel lubricating oil sales;Technical development, design, sales, leasing, repair, maintenance and technical services of gas engines, combustible gas generator sets, diesel engines and diesel generator sets;Technical development, design and sales of the above machine spare parts and required auxiliary materials, mechanical equipment, instruments and meters, power station equipment, industrial monitoring system equipment;Import and export business.(For projects that must be approved according to law, business activities can only be carried out after being approved by relevant departments.) Jinan Guohua Lveng Power Equipment Co., Ltd. has one branch.

After nearly ten years development, the company has formed a complete ,mature sales and maintenance service system. At present, the company has set up a warehouse in Jinan and XinJiang, covering an area of more than 1,000 square meters, And the company also has 2000 square meters of engine overhaul and stalling workshop in jinan, with assets of 30 million yuan, more than50 employees. At present, the company has obtained SGS general notary certificate, 190 series engine agent certificate.

The company's sales network has been continuously expanded. It has established stable supply and marketing relationships with clients from 32 provinces, municipalities and autonomous regions in China.Also the products are sold overseas and have been sold to 20 countries including Asia, Africa, America, and the Commonwealth of Independent States.
Companies adhere to the "quality first, scientific management, customer first, integrity-based" purposes, which are in accordance with the "integrity, pragmatic, pioneering, innovative" spirit of enterprise, so as to meet the needs of users with first class service.

Warmly welcome friends from all walks of life to review, cooperate and create brilliance

Model of genset	Model of engine	Rated Power(KW/KVA)	Rated Voltage(V)	Rated Frequency(HZ)	Overall Dimension LBH(mm)	Net weigh(KG)	Fuel
700GF-TK2	A12V190ZLT-2	700/875	400/230	50	562021802520	16000	natural gas
800GF-W	AD12V190ZLW-2	800/1000	400/230	50	704023352520	20200	coal mine gas
1000GF-NK	AD12V190ZLZ	1000/1250	400/230	50	537523122776.5	16500	biogas
1000GF-TK1	AD12V190ZLT1	1000/1250	400/230	50	537523122776.5	16500	natural gas
1000GF-TK2	AD12V190ZLT2	1000/1250	400/230	50	537523122776.5	16500	natural gas
1000GFZ-TK2	AD12V190ZLT3	1000/1250	400/230	50	537523122776.5	16500	natural gas
1000GF-T	AD12V190ZLT2	1000/1250	400/230	50	666023352520	19800	natural gas
1000GF-T3	AD12V190ZLT2	1000/1250	400/230	50	666023352520	19800	natural gas
1000GF-T4	AD12V190ZLT2	1000/1250	400/230	50	666023352520	19800	natural gas
1100GF-WK	H16V190ZLW-2	1100/1375	400/230	50	592021802200	17200	coal mine gas
Main specification for gas engines
Model	Rated Power(KW)	Rated Speed(r/min)	Compression ratio	Specific heat consumption(kj/kw.h)	Specific oil consumption(g/kw.h)	Overall Dimension LBH(mm)	Net weigh(KG)	FUEL
AD12V190ZLT1	1100	1500	12:01	≤11000	≤1.6	297923122471	9300	natural gas
AD12V190ZLT2	1100	1500	10:01	≤9500	≤1.0	297923122471	9300	natural gas
AD12V190ZLT3	1100	1500	10:01	≤9500	≤1.0	297923122471	9300	natural gas
AD12V190ZLW-2	900	1000	10:01	≤9500	≤1.0	297923122471	9300	coal mine gas
H12V190ZLT	1500	1500	12:01	≤9500	≤1.0	383017922315	9300	natural gas
H16V190ZLT-2	1200	1000	10:01	≤9500	≤1.0	369225162405	13000	natural gas
H16V190ZLW-2	1200	1000	10:01	≤9500	≤1.0	369225162405	13000	natural gas
