Jichai G12V190pzl-3 Low Speed Combustion Engine for Oil Field Drilling Performance

Large Image : Jichai G12V190pzl-3 Low Speed Combustion Engine for Oil Field Drilling Performance

Product Details:

Place of Origin:	china
Certification:	ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	10-1000
Packaging Details:	Wooden box and carton packaging
Delivery Time:	15 days
Payment Terms:	TT,western

Contact Now

Jichai G12V190pzl-3 Low Speed Combustion Engine for Oil Field Drilling Performance

Description

Model NO.:	12V190	Number Of Strokes:	Four-Stroke
Cylinder Arrangement Form:	V	Number Of Cylinders:	12-Cylinder
Type:	Combustion Engine	Transport Package:	Wooden Cases
Specification:	11111	Trademark:	JICHAI
Origin:	China	HS Code:	8409999000
Supply Ability:	50000pecises/Year	Ignition Mode:	Electric Ignition
Speed:	Low Speed	Cooling Cylinder:	Water-Cooled
Intake Pressure Impulse:	Supercharged	Piston Movement:	Reciprocating
Fuel:	Diesel	Customization:	Available \| Customized Request

series 2000 diesel engines
series 2000 diesel engines
Model	Rated Power(KW/hp)	Rated Speed(r/min)		Specific fuel consumption(g/kw.h)	Specific oil consumption(g/kw.h)	Overall Dimension LBH(mm)	Net weigh(KG)
BG12V190ZL	900/1500	800/1500	≤209.4		≤1.6	316017702400	5300
BG12V190PZL	900/1500	800/1500	≤209.4		≤1.6	437417402400	8100
BG12V190ZL-3	810/1300	730/1300	≤209.4		≤1.6	316017702400	5300
BG12V190PZL-3	810/1300	730/1300	≤209.4		≤1.6	437417402400	8100
G12V190ZL	900/1500	800/1500	≤209.4		≤1.6	269215602070	5300
G12V190PZL	900/1500	800/1500	≤209.4		≤1.6	386020402678	8100
G12V190ZL-3	810/1300	730/1300	≤209.4		≤1.6	269215602070	5300
G12V190PZL-3	810/1300	730/1300	≤209.4		≤1.6	386020402678	8100
G12V190ZL-1	740/1200	660/1200	≤209.4		≤1.6	269215602070	5300
G12V190PZL-1	740/1200	660/1200	≤209.4		≤1.6	386020402678	8100
G12V190ZL-2	600/1000	540/1000	≤209.4		≤1.6	269215602070	5300
G12V190PZL-2	600/1000	540/1000	≤209.4		≤1.6	386020402678	8100
G8V190ZL	600/1500	540/1500	≤213.5		≤2.7	180215602070	4300
G8V190PZL	600/1500	540/1500	≤213.5		≤2.7	328020402678	6750
G8V190ZL-3	510/1300	460/1300	≤213.5		≤2.7	180215602070	4300
G8V190PZL-3	510/1300	460/1300	≤213.5		≤2.7	328020402678	6750
G8V190ZL-1	470/1200	425/1200	≤213.5		≤2.7	180215602070	4300
G8V190PZL-1	470/1200	425/1200	≤213.5		≤2.7	328020402678	6750
G8V190ZL-2	390/1000	350/1000	≤213.5		≤2.7	180215602070	4300
G8V190PZL-2	390/1000	350/1000	≤213.5		≤2.7	328020402678	6750
Main technical data
No. and arrangement of cylinders:12,60.Vee
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:210mm
Total displacement:71.45(47.6)L
Compression ration:14:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication

Jinan Guohua Green Power Equipment Co., Ltd. is located in the beautiful city of Quancheng----Jinan City. As an emerging development enterprise in Shandong Province and a green energy utilization enterprise.Jinan Guohua mainly engaged in the sales and maintenance of 190 series diesel generator sets and gas generator sets and their accessories.
After nearly ten years of continuous development, the company has formed a complete and mature sales and maintenance service system. At present, the company has set up a warehouse in Jinan and Xinjiang, covering an area of more than 1,000 square meters, with assets of 30 million yuan, more than 50 employees, including 20 technicians. At present, the company has obtained SGS general notary certificate,Jichai agent certificate.
The company's sales network has been continuously expanded. It has established stable supply and marketing relationships with 32 provinces, municipalities and autonomous regions in China, and has import and export rights. The products are sold overseas and have been sold to 20 countries including Asia, Africa, America, and the Commonwealth of Independent States. The above countries have established a solid cooperative relationship.
The company's main products:
I.: Jichai(chidong) / Shengdong 190 series gas engine parts, diesel engine parts.
II: Jichai(chidong) 190 series gas engine, diesel engine host.
III: 190 series engine overhaul and maintenance.
IV: the transportation of the power station.
Companies adhere to the "quality first, scientific management, customer first, integrity-based" purposes, in accordance with the "integrity, pragmatic, pioneering, innovative" spirit of enterprise, to meet the needs of users with first-class service.
Warmly welcome friends from all walks of life to review, cooperate and create brilliance together!

Jichai Brand Drilling Engine G12V190pzl-3 Used in Oil Field
