Naturally Aspirated Intake Pressure Impulse Ignition Jichai 500kw Engine Generator Set

Large Image : Naturally Aspirated Intake Pressure Impulse Ignition Jichai 500kw Engine Generator Set

Product Details:

Place of Origin:	china
Certification:	ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	10-1000
Packaging Details:	Wooden box and carton packaging
Delivery Time:	15 days
Payment Terms:	TT,western

Contact Now

Naturally Aspirated Intake Pressure Impulse Ignition Jichai 500kw Engine Generator Set

Description

Model NO.:	Z12V190B	Piston Movement:	Reciprocating
Fuel:	Diesel	Number Of Strokes:	Four-Stroke
Cylinder Arrangement Form:	V	Number Of Cylinders:	12-Cylinder
Type:	Combustion Engine	Product Material:	Steel
Transport Package:	Wooden Cases	Specification:	1000
Trademark:	Jichai	Origin:	China
HS Code:	8409999000	Supply Ability:	50000pecises/Year
After-sales Service:	Online Services	Warranty:	3 Months
Ignition Mode:	Ignition	Speed:	High Speed
Cooling Cylinder:	Water-Cooled	Intake Pressure Impulse:	Naturally Aspirated
Customization:	Available \| Customized Request

Model Z12V190B diesel engines
Model Z12V190B diesel engines
Model	Rated Power(KW/hp)	Rated Speed(r/min)		Specific fuel consumption(g/kw.h)	Specific oil consumption(g/kw.h)	Overall Dimension LBH(mm)	Net weigh(KG)
Z12V190B	882/1500	794/1500	≤209.4		≤1.6	269215602070	5300
PZ12V190B	882/1500	794/1500	≤209.4		≤1.6	430119802678	7500
Z12V190B-3	820/1300	738/1300	≤209.4		≤1.6	269215602070	5300
PZ12V190B-3	820/1300	738/1300	≤209.4		≤1.6	430119802678	7500
Z12V190B-1	735/1200	662/1200	≤209.4		≤1.6	269215602070	5300
PZ12V190B-1	735/1200	662/1200	≤209.4		≤1.6	430119802678	7500
Z12V190B-2	588/1000	529/1000	≤209.4		≤1.6	269215602070	5300
PZ12V190B-2	588/1000	529/1000	≤209.4		≤1.6	430119802678	7500
Z8V190	588/1500	529/1500	≤213.5		≤2.7	211215602080	4300
PZ8V190	588/1500	529/1500	≤213.5		≤2.7	395019802678	6750
Z8V190-1	471/1200	425/1200	≤213.5		≤2.7	211215602080	4300
PZ8V190-1	471/1200	425/1200	≤213.5		≤2.7	395019802678	6750
Z8V190-2	390/1000	350/1000	≤213.5		≤2.7	211215602080	4300
PZ8V190-2	390/1000	350/1000	≤213.5		≤2.7	395019802678	6750
Main technical data
No. and arrangement of cylinders:12,60.Vee
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:210mm
Total displacement:71.45L
Compression ration:14:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication
series 2000 diesel engines
series 2000 diesel engines
Model	Rated Power(KW/hp)	Rated Speed(r/min)		Specific fuel consumption(g/kw.h)	Specific oil consumption(g/kw.h)	Overall Dimension LBH(mm)	Net weigh(KG)
BG12V190ZL	900/1500	800/1500	≤209.4		≤1.6	316017702400	5300
BG12V190PZL	900/1500	800/1500	≤209.4		≤1.6	437417402400	8100
BG12V190ZL-3	810/1300	730/1300	≤209.4		≤1.6	316017702400	5300
BG12V190PZL-3	810/1300	730/1300	≤209.4		≤1.6	437417402400	8100
G12V190ZL	900/1500	800/1500	≤209.4		≤1.6	269215602070	5300
G12V190PZL	900/1500	800/1500	≤209.4		≤1.6	386020402678	8100
G12V190ZL-3	810/1300	730/1300	≤209.4		≤1.6	269215602070	5300
G12V190PZL-3	810/1300	730/1300	≤209.4		≤1.6	386020402678	8100
G12V190ZL-1	740/1200	660/1200	≤209.4		≤1.6	269215602070	5300
G12V190PZL-1	740/1200	660/1200	≤209.4		≤1.6	386020402678	8100
G12V190ZL-2	600/1000	540/1000	≤209.4		≤1.6	269215602070	5300
G12V190PZL-2	600/1000	540/1000	≤209.4		≤1.6	386020402678	8100
G8V190ZL	600/1500	540/1500	≤213.5		≤2.7	180215602070	4300
G8V190PZL	600/1500	540/1500	≤213.5		≤2.7	328020402678	6750
G8V190ZL-3	510/1300	460/1300	≤213.5		≤2.7	180215602070	4300
G8V190PZL-3	510/1300	460/1300	≤213.5		≤2.7	328020402678	6750
G8V190ZL-1	470/1200	425/1200	≤213.5		≤2.7	180215602070	4300
G8V190PZL-1	470/1200	425/1200	≤213.5		≤2.7	328020402678	6750
G8V190ZL-2	390/1000	350/1000	≤213.5		≤2.7	180215602070	4300
G8V190PZL-2	390/1000	350/1000	≤213.5		≤2.7	328020402678	6750
Main technical data
No. and arrangement of cylinders:12,60.Vee
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:210mm
Total displacement:71.45(47.6)L
Compression ration:14:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication
