Diesel engine parameters: Diesel engine model;Z12V190B Type four stroke, direct injection combustion chamber, water - cooled, pressurized and intercooled Number of cylinders and arrangement of 12 cylinder V 60° included Angle Cylinder diameter × stroke -- mm 190×210 Total piston displacement -L 71.45 Rated speed -- r/min 1500 Average piston speed -m/S 10.5 Calibration power -- KW 1000 Fuel consumption rate -- g/ kW.h 209.4 Oil consumption rate -- g/ kW.h 1.6 Compression ratio 14;1 Cooling method Forced cooling Lubrication mode pressure and splash lubrication Overall dimension - mm 2692*1560*2070 Weight - 5300 kg Exhaust temperature (before turbine, ºC) ≤600 The outlet water temperature (ºC) ≤85 1000KW diesel engine parameters Diesel engine G12V190ZL1 parameters: Type four stroke, direct injection combustion chamber, water - cooled, pressurized and intercooled Number of cylinders and arrangement of 12 cylinder V 60° included Angle Cylinder diameter × stroke -- mm 190×210 Total piston displacement -L 71.45 Rated speed -- r/min 1500 Calibration power -- KW 1000 Fuel consumption rate -- g/ kW.h ≤209.4±5% Oil consumption rate -- g/ kW.h ≤1.6 Cooling method Forced cooling Lubrication mode pressure and splash lubrication Unit size -mm 2642*1560*2070 Weight - 5300 kg |
