ISO Certified Jichai 12V190 Gas Engine Parts in Ukraine Standard and Affordable

ISO Certified Jichai 12V190 Gas Engine Parts in Ukraine Standard and Affordable
ISO Certified Jichai 12V190 Gas Engine Parts in Ukraine Standard and Affordable ISO Certified Jichai 12V190 Gas Engine Parts in Ukraine Standard and Affordable ISO Certified Jichai 12V190 Gas Engine Parts in Ukraine Standard and Affordable ISO Certified Jichai 12V190 Gas Engine Parts in Ukraine Standard and Affordable ISO Certified Jichai 12V190 Gas Engine Parts in Ukraine Standard and Affordable ISO Certified Jichai 12V190 Gas Engine Parts in Ukraine Standard and Affordable

Large Image :  ISO Certified Jichai 12V190 Gas Engine Parts in Ukraine Standard and Affordable

Product Details:
Place of Origin: china
Certification: ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 10-1000
Packaging Details: Wooden box and carton packaging
Delivery Time: 15 days
Payment Terms: TT,western
Contact Now

ISO Certified Jichai 12V190 Gas Engine Parts in Ukraine Standard and Affordable

Description
Model NO.: 12V190 Specification: 11
Trademark: JICHAI Origin: China
HS Code: 8409999000 Supply Ability: 50000pecises/Year
Output Type: DC Gas Source: Natural Gas
Certification: ISO Power: ＞200kW
Standard: Standard Transport Package: Wooden Cases
Customization: Available | Customized Request

Jichai 12V190 Gas Engine Parts in Ukrine
Main specification for gas gesets
Model of genset Model of engine Rated Power(KW/KVA) Rated Voltage(V) Rated Frequency(HZ) Overall Dimension L*B*H(mm) Net weigh(KG) Fuel
400GF-MK1 12V190ZLM-2 400/500 400/230 50 5120*2040*2678 12000 coal gas
500GF-TK G12V190ZLT-2 500/625 400/230 50 5120*2040*2678 12000 natural gas
500GF-MK1 12V190ZLM 500/625 400/230 50 5120*2040*2678 12000 coal gas
500GF-MK2 12V190ZLM-2 500/625 400/230 50 5120*2040*2678 12000 coal gas
500GF-LK G12V190ZL-2 500/625 400/230 50 5120*2040*2678 12000 refinery gas
700GF-TK G12V190ZLT 700/875 400/230 50 5120*2040*2678 12000 natural gas
Main specification for gas engines
Model Rated Power(KW) Rated Speed(r/min) Compression ratio No.and layout of cylinders Overall Dimension L*B*H(mm) Net weigh(KG) Fuel
12V190ZLM-2 450 1000 10:01 12,60.Vee 2785*1628*2437 5300 coal gas
G12V190ZLL-2 550 1000 10:01 12,60.Vee 2785*1628*2437 5300 refinery gas
12V190ZLM 550 1500 10:01 12,60.Vee 2785*1628*2437 5300 coal gas
G12V190ZLT-2 600 1000 10:01 12,60.Vee 2785*1628*2437 5300 natural gas
12V190ZLZ 700 1500 10:01 12,60.Vee 2785*1628*2437 5300 biogas
G12V190ZLT 800 1500 10:01 12,60.Vee 2785*1628*2437 5300 natural gas
12V190ZLT 800 1500 10:01 12,60.Vee 2670*1588*2538 5300 natural gas
Main technical data
Type:Four stroke,water cooled,turbocharged and aftercooled,spark plug ignition,outer mixing
Bore:190mm
Stroke:210mm
Direction of rotation:Counter-clockwise(facing to flywheel)
Starting method: electric motor
Lubricating method:Pressure and splash lubrication
Specific heat consumption:≤9800KJ/KW·h
Specific oil consumption:≤1.6g/KW·h
Stable speed regulating rate:0-5%adjustable
Jichai 12V190 Gas Engine Parts in Ukrine
Jinan Guohua Green Power Equipment Co.,Ltd(JNGH),is a high-tech sales &service company of Jinan Diesel Engine Co., Ltd. Established in 2010,JNGH has formed a complete system in sales and after-sales of 190 series engine(jichai brand:6L190,8V190,12V190.16V190)
Main business scope:
Early stage:Consultation,designation, supply and erection of engine-based power plants,including diesel generator,natural gas generator,coal gas generator and biogas generator.
Mid stage:Parts supply of jinan diesel engine(jichai/chidong brand).JNGH has two warehouses.One located in Jinan which supply the domestic north and south market.One located in Xinjiang province which supply the west market.Thus could delivery parts fast and guarantee the quality.
Later stage:JNGH also offer engine overhaul and maintenance service.With experienced engineer and professional skills,the problems could be easy solved.Not only the domestic China,Ghana,Kazakhstan,Vietnam and Myanmar also could see the trace of JNGH.
Later stage:Overhaul and maintenance service offered.
Power project consultation and design, integrated OEM, and spare parts supply are offered by JNGH.As well as this, JNGH provides engine overhaul and maintenance services, and power plant investment. JCHN is also capable of providing EPC integrated solutions and turn-key projects of fuel gas comprehensive utilization system, combined heat utilization system (CHP or CCHP), water treatment system, etc.established in 2010,is a high-tech enterprise specialized in 190 series engine.(6L190,8V190,12V190,16V190).
