8190zlc Chidong Marine Engine Parts for Passenger Ships Push and Standard Component

8190zlc Chidong Marine Engine Parts for Passenger Ships Push and Standard Component
8190zlc Chidong Marine Engine Parts for Passenger Ships Push and Standard Component 8190zlc Chidong Marine Engine Parts for Passenger Ships Push and Standard Component 8190zlc Chidong Marine Engine Parts for Passenger Ships Push and Standard Component 8190zlc Chidong Marine Engine Parts for Passenger Ships Push and Standard Component 8190zlc Chidong Marine Engine Parts for Passenger Ships Push and Standard Component 8190zlc Chidong Marine Engine Parts for Passenger Ships Push and Standard Component

Large Image :  8190zlc Chidong Marine Engine Parts for Passenger Ships Push and Standard Component

Product Details:
Place of Origin: china
Certification: ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 10-1000
Packaging Details: Wooden box and carton packaging
Delivery Time: 15 days
Payment Terms: TT,western
Contact Now

8190zlc Chidong Marine Engine Parts for Passenger Ships Push and Standard Component

Description
Model NO.: 8190 Specification: 118
Trademark: Jichai Origin: China
HS Code: 8409999000 Supply Ability: 50000pecises/Year
Certification: ISO9001, CE Standard Component: Standard Component
Technics: Push Material: Aluminum
Type: The Piston Pin Transport Package: Wooden Cases
Customization: Available | Customized Request

8190zlc Chidong Brand Marine Engine Parts Used in Passanger Ships
Series B3000 diesel engines
Model Rated Power(KW/hp) Rated Speed(r/min) Specific fuel consumption(g/kw.h) Specific oil consumption(g/kw.h) Overall Dimension L*B*H(mm) Net weigh(KG)
B12V190ZL 1320/1500 1200/1500   ≤202 ≤1.0 2950*1980*2206 9300
B12V190PZL 1320/1500 1200/1500   ≤202 ≤1.0 3980*2250*2739 11000
B12V191ZL-1 1140/1200 1040/1200   ≤202 ≤1.0 2950*1980*2206 9300
B12V191PZL-1 1140/1200 1040/1200   ≤202 ≤1.0 3980*2250*2739 11000
B12V191ZL-2 930/1000 840/1000   ≤202 ≤1.0 2950*1980*2206 9300
B12V191PZL-2 930/1000 840/1000   ≤202 ≤1.0 3980*2250*2739 11000
B12V191ZL-3 1180/1300 1080/1300   ≤202 ≤1.0 2950*1980*2206 9300
B12V191PZL-3 1180/1300 1080/1300   ≤202 ≤1.0 3980*2250*2739 11000
BH12V190ZL 1360/1500 1235/1500   ≤202 ≤1.0 2950*2280*2069 9300
BH12V190PZL 1360/1500 1235/1500   ≤202 ≤1.0 4198*2345*2636 11000
BH12V191ZL-1 1160/1200 1060/1200   ≤202 ≤1.0 2950*2280*2069 9300
BH12V191PZL-1 1160/1200 1060/1200   ≤202 ≤1.0 4198*2345*2636 11000
BH12V191ZL-2 960/1000 870/1000   ≤202 ≤1.0 2950*2280*2069 9300
BH12V191PZL-2 960/1000 870/1000   ≤202 ≤1.0 4198*2345*2636 11000
BH12V191ZL-3 1210/1300 1100/1300   ≤202 ≤1.0 2950*2280*2069 9300
BH12V191PZL-3 1210/1300 1100/1300   ≤202 ≤1.0 4198*2345*2636 11000
Main technical data
No. and arrangement of cylinders:12,60.Vee
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:215mm
Total displacement:73.15L
Compression ration:14.5:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication
8190zlc Chidong Brand Marine Engine Parts Used in Passanger Ships

Jinan Guohua Green Power Equipment Co.,Ltd(JNGH),is a high-tech sales &service company of Jinan Diesel Engine Co., Ltd. Established in 2010,JNGH has formed a complete system in sales and after-sales of 190 series engine(jichai brand:6L190,8V190,12V190.16V190) after eight years experience.
Main business scope:
Early stage:Consultation,designation, supply and erection of engine-based power plants,including diesel generator,natural gas generator,coal gas generator and biogas generator.
Mid stage:Parts supply of jinan diesel engine(jichai/chidong brand).JNGH has two warehouses.One located in Jinan which supply the domestic north and south market.One located in Xinjiang province which supply the west market.Thus could delivery parts fast and guarantee the quality.
Later stage:JNGH also offer engine overhaul and maintenance service.With experienced engineer and professional skills,the problems could be easy solved.Not only the domestic China,Ghana,Kazakhstan,Vietnam and Myanmar also could see the trace of JNGH.
8190zlc Chidong Brand Marine Engine Parts Used in Passanger Ships
12VB.05.10.04/05 connecting rod bearing
12VB.01.23A/24A UPPER/LOWER MAIN BEARING METAL
12VB.01.21A/22A LOWER/UPPER THRUST MAIN BEARING
12VB.01.34 CAMSHAFT BEARING
12VB.01.25A THRUST PLATE
12VB.05.09C-GJ piston ring
12V.01.02C cylinder liner
12VB.03.80.05 SEAT,INLET VALVE
12VB.03.37A INLET VALVE
12VB.03.80.05 SEAT,EXHAUST VALVE
12VB.03.22 EXHAUST VALVE
12VB.03.19 SPRING SEAT,LOWER
12VB.03.15 SPRING SEAT,UPPER
Z12V.03.17A VALVE SPRING,INNER
Z12V.03.18A VALVE SPRING,OUTER
12VB.03.80.02 VALVE GUIDE
12VB.03.02 UPPER COCVER,CYLINDER HEAD
12VB.03.11 SEAL RING I
12VB.03.14E LOWER COVER,CYLINDER HEAD
12VB.03.12A SEAL RING II
601.01.25 THRUST PLATE
601.01.23/24 MAIN BEARING METAL
601.05.07/08 CONNECTING ROD BEARING
601.01.34 CAMSHAFT BEARING
B4012C.05.10.04/05 CONNECTING ROD BEARING
