Piston Ring and CE Certified 12V190 Sand Pump Vessel Engine Parts for Your Requirements

Piston Ring and CE Certified 12V190 Sand Pump Vessel Engine Parts for Your Requirements
Piston Ring and CE Certified 12V190 Sand Pump Vessel Engine Parts for Your Requirements Piston Ring and CE Certified 12V190 Sand Pump Vessel Engine Parts for Your Requirements Piston Ring and CE Certified 12V190 Sand Pump Vessel Engine Parts for Your Requirements Piston Ring and CE Certified 12V190 Sand Pump Vessel Engine Parts for Your Requirements Piston Ring and CE Certified 12V190 Sand Pump Vessel Engine Parts for Your Requirements Piston Ring and CE Certified 12V190 Sand Pump Vessel Engine Parts for Your Requirements

Large Image :  Piston Ring and CE Certified 12V190 Sand Pump Vessel Engine Parts for Your Requirements

Product Details:
Place of Origin: china
Certification: ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 10-1000
Packaging Details: Wooden box and carton packaging
Delivery Time: 15 days
Payment Terms: TT,western
Contact Now

Piston Ring and CE Certified 12V190 Sand Pump Vessel Engine Parts for Your Requirements

Description
Model NO.: 12V190 Specification: 100kg
Trademark: Jichai Origin: China
HS Code: 8409919990 Supply Ability: 50000pecises/Year
Certification: ISO9001, CE Standard Component: Standard Component
Technics: Push Material: Aluminum
Type: Piston Ring Transport Package: Wooden Cases
Customization: Available | Customized Request

12V190 Sand Pump Vessel Engine Parts


Jinan Guohua Green Power Equipment Co.,Ltd(JNGH),is a high-tech sales &service company of Jinan Diesel Engine Co., Ltd. Established in 2010,JNGH has formed a complete system in sales and after-sales of 190 series engine(jichai brand:6L190,8V190,12V190.16V190) after eight years experience.
Main business scope:
Early stage:Consultation,designation, supply and erection of engine-based power plants,including diesel generator,natural gas generator,coal gas generator and biogas generator.

Mid stage:Parts supply of jinan diesel engine(jichai/chidong brand).JNGH has two warehouses.One located in Jinan which supply the domestic north and south market.One located in Xinjiang province which supply the west market.Thus could delivery parts fast and guarantee the quality.

Later stage:JNGH also offer engine overhaul and maintenance service.With experienced engineer and professional skills,the problems could be easy solved.Not only the domestic China,Ghana,Kazakhstan,Vietnam and Myanmar also could see the trace of JNGH.
12V190 Sand Pump Vessel Engine Parts

      Series 2000V marine diesel engines
Model Rated Power(kw/hp) Rated speed(r/min) Specific fuel consumption(g/kw'h) Specific oil consumption(g/kw'h) Overall dimension L*B*H(mm) Net weight(kg)
Z12V190BC1 800/1080 1500 ≤209.4 ≤1.6 2642*1588*2070 5300
Z12V190BC2 882/1200 1500 ≤209.4 ≤1.6 2642*1588*2070 5300
Z12V190BC8 1000/1360 1500 ≤209.4 ≤1.6 2642*1588*2070 5300
Z12V190BC9 882/1200 1500 ≤209.4 ≤1.6 2642*1588*2070 5300
Z12V190BC10 900/1225 1450 ≤209.4 ≤1.6 2642*1588*2070 5300
Z12V190BC11 882/1200 1500 ≤209.4 ≤1.6 2642*1588*2070 5300
G12V190ZLC1 1000/1360 1450 ≤209.4 ≤1.6 2642*1588*2070 5300
G12V190ZLC2 1000/1360 1450 ≤209.4 ≤1.6 2642*1588*2070 5300
Main technical data
No. and arrangement of cylinders:12,60.Vee
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:210mm
Total displacement:71.45L
Compression ration:14:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication
Model of generating set Model of diesel engines Model of generator Rated Power KW Rated voltage V Rated frequency HZ Overall dimension L*B*H(mm) Net weight KG
CCFJ400/1000 Z12V190BCD-2 TFC5454-6JH42 400 390 50 4210*1500*2260 10500
CCFJ630/1500 Z12V190BCD TFC5456-4JH42 630 390 50 4260*1500*2260 12000
12V190 Sand Pump Vessel Engine Parts
