600kw G8V190zl Co600f/25 Jinan Diesel Engine Push for Power Generation Machinery

600kw G8V190zl Co600f/25 Jinan Diesel Engine Push for Power Generation Machinery
600kw G8V190zl Co600f/25 Jinan Diesel Engine Push for Power Generation Machinery 600kw G8V190zl Co600f/25 Jinan Diesel Engine Push for Power Generation Machinery 600kw G8V190zl Co600f/25 Jinan Diesel Engine Push for Power Generation Machinery 600kw G8V190zl Co600f/25 Jinan Diesel Engine Push for Power Generation Machinery 600kw G8V190zl Co600f/25 Jinan Diesel Engine Push for Power Generation Machinery 600kw G8V190zl Co600f/25 Jinan Diesel Engine Push for Power Generation Machinery

Large Image :  600kw G8V190zl Co600f/25 Jinan Diesel Engine Push for Power Generation Machinery

Product Details:
Place of Origin: china
Certification: ISO9001
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 10-1000
Packaging Details: Wooden box and carton packaging
Delivery Time: 15 days
Payment Terms: TT,western
Contact Now

600kw G8V190zl Co600f/25 Jinan Diesel Engine Push for Power Generation Machinery

Description
Model NO.: 12V190 Specification: 118
Trademark: Jichai Origin: China
HS Code: 8409999000 Supply Ability: 50000pecises/Year
Certification: ISO9001, CE Standard Component: Standard Component
Technics: Push Material: Aluminum
Type: The Piston Pin Transport Package: Wooden Cases
Customization: Available | Customized Request

Co600f/25 Jinan Diesel Engine 600kw G8V190zl
series 3000 diesel engines
Model Rated Power(KW/hp) Rated Speed(r/min) Specific fuel consumption(g/kw.h) Specific oil consumption(g/kw.h) Overall Dimension L*B*H(mm) Net weigh(KG)
A12V190ZL 1200/1500 1080/1500 ≤205 ≤1.0 2950*1980*2206 9300
A12V190PZL 1200/1500 1080/1500 ≤205 ≤1.0 3980*2250*2739 11000
A12V190ZL-3 1100/1300 990/1300 ≤205 ≤1.0 2950*1980*2206 9300
A12V190PZL-3 1100/1300 990/1300 ≤205 ≤1.0 3980*2250*2739 11000
A12V190ZL-1 1000/1200 900/1200 ≤205 ≤1.0 2950*1980*2206 9300
A12V190PZL-1 1000/1200 900/1200 ≤205 ≤1.0 3980*2250*2739 11000
A12V190ZL-2 900/1000 810/1000 ≤205 ≤1.0 2950*1980*2206 9300
A12V190PZL-2 900/1000 810/1000 ≤205 ≤1.0 3980*2250*2739 11000
A8V190ZL 900/1500 810/1500 ≤205 ≤1.4 2300*1774*2173 7200
A8V190PZL 900/1500 810/1500 ≤205 ≤1.4 3380*2250*2738 9100
A8V190ZL-3 760/1300 684/1300 ≤205 ≤1.4 2300*1774*2173 7200
A8V190PZL-3 760/1300 684/1300 ≤205 ≤1.4 3380*2250*2738 9100
A8V190ZL-1 700/1200 630/1200 ≤205 ≤1.4 2300*1774*2173 720
A8V190PZL-1 700/1200 630/1200 ≤205 ≤1.4 3380*2250*2738 9100
A8V190ZL-2 600/1000 540/1000 ≤205 ≤1.4 2300*1774*2173 720
A8V190PZL-2 600/1000 540/1000 ≤205 ≤1.4 3380*2250*2738 9100
Main technical data
No. and arrangement of cylinders:12,60.Vee
Type:Four stroke,water cooled,turbocharged and aftercooled,direct injection
Bore:190mm
Stroke:215mm
Total displacement:73.15(48.77)L
Compression ration:14.5:1
Direction of rotation:Counter-clockwise engine without R,clockwise engine with R in the model(facing to flywheel)
Starting method:Air motor or electric motor
Lubricating method:Pressure and splash lubrication

Co600f/25 Jinan Diesel Engine 600kw G8V190zl

Jinan Guohua Green Power Equipment Co.,Ltd(JNGH),is a high-tech sales &service company of Jinan Diesel Engine Co., Ltd. Established in 2010,JNGH has formed a complete system in sales and after-sales of 190 series engine(jichai brand:6L190,8V190,12V190.16V190) after eight years experience.
Main business scope:
Early stage:Consultation,designation, supply and erection of engine-based power plants,including diesel generator,natural gas generator,coal gas generator and biogas generator.
Mid stage:Parts supply of jinan diesel engine(jichai/chidong brand).JNGH has two warehouses.One located in Jinan which supply the domestic north and south market.One located in Xinjiang province which supply the west market.Thus could delivery parts fast and guarantee the quality.
Later stage:JNGH also offer engine overhaul and maintenance service.With experienced engineer and professional skills,the problems could be easy solved.Not only the domestic China,Ghana,Kazakhstan,Vietnam and Myanmar also could see the trace of JNGH.
Co600f/25 Jinan Diesel Engine 600kw G8V190zl
12VB.05.10.04/05 connecting rod bearing
12VB.01.23A/24A UPPER/LOWER MAIN BEARING METAL
12VB.01.21A/22A LOWER/UPPER THRUST MAIN BEARING
12VB.01.34 CAMSHAFT BEARING
12VB.01.25A THRUST PLATE
12VB.05.09C-GJ piston ring
12V.01.02C cylinder liner
12VB.03.80.05 SEAT,INLET VALVE
12VB.03.37A INLET VALVE
12VB.03.80.05 SEAT,EXHAUST VALVE
12VB.03.22 EXHAUST VALVE
12VB.03.19 SPRING SEAT,LOWER
12VB.03.15 SPRING SEAT,UPPER
Z12V.03.17A VALVE SPRING,INNER
Z12V.03.18A VALVE SPRING,OUTER
12VB.03.80.02 VALVE GUIDE
12VB.03.02 UPPER COCVER,CYLINDER HEAD
12VB.03.11 SEAL RING I
12VB.03.14E LOWER COVER,CYLINDER HEAD
12VB.03.12A SEAL RING II
601.01.25 THRUST PLATE
601.01.23/24 MAIN BEARING METAL
601.05.07/08 CONNECTING ROD BEARING
601.01.34 CAMSHAFT BEARING
B4012C.05.10.04/05 CONNECTING ROD BEARING
